Flexible Twisted 24 Pairs Shielded Instrument Cable With XLPE PVC Insulation Copper Conductor

Product Categories
Minfeng Cable Group Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Flexible Twisted 24 Pairs Shielded Instrument Cable With XLPE PVC Insulation Copper Conductor

Brand Name : Minfeng

Model Number : instrument cable

Certification : ISO,CE,IEC,TUV,KEMA

Place of Origin : Hebei, China

MOQ : 100

Price : 0.1-5

Payment Terms : L/C,T/T

Supply Ability : 100KM/Week

Delivery Time : 10 Days

Shieldtype : Foil and Braid

Jacketcolor : Black or custom

Outer Sheath Color : as required

Packing : 500m/Reel

Sample : Available

Shipping : by Container

Conductor : Copper Conductor

Voltage : 300/500V 450/750V

Contact Now

Flexible Twisted 24 Pairs 0.75mm² 1mm² 1.5mm² Multi Pair Core CU XLPE PVC PVC Electrical Instrument Instrumentation Cable
Shielding
Braid
Conductor Material
Copper
Insulation Material
XLPE PVC
Jacket
PVC
Place of Origin
Hebei, China
Model Number
OEM
Brand Name
Minfeng
Product Name
Instrument Cable
Voltage
300/500V 450/750V
Material
Copper PVC
Color
Black
Connector
Copper Core
Wire
0.35mm
Type
Traid
Certificate
ROHS
Flexible Twisted 24 Pairs Shielded Instrument Cable With XLPE PVC Insulation Copper Conductor
Cable Construction

Conductor: Plain Annealed Copper, Class 2 Stranded Circular

Insulation: (1) Polyvinyl Chloride (PVC) Compound Type Ti51 or (2) Cross-linked Polyethylene (XLPE) Compound

Insulation Colour: Pair/s - Black/White with Black numberings; Triad/s - Red/Black/White with Black numberings

Cores Twisted: Cores twisted to form a pair, triad or quad

Lay Up: Multi-pairs, triads or quads are assembled together in concentric layers to form the cable core

Wrap Film: Polyester Binder Tape

Overall Screen: Aluminium/Polyester Tape, with a Tinned Copper Drain Wire 0.5mm² (7/0.3mm)(0S)

Outer Sheath: Flame Retardancy Polyvinyl Chloride (PVC) Compound Type ST2 FR

Outer Sheath Colour: Black or Blue

Flexible Twisted 24 Pairs Shielded Instrument Cable With XLPE PVC Insulation Copper Conductor
XLPE Material Properties

XLPE is a new type of environmentally friendly product with high-temperature resistance and environmental resistance. It is made of thermosetting plastic. The electrical properties of XLPE cables are as good as polyethylene, and the long-term working temperature is relatively higher than that of polyethylene. At the same time, the mechanical properties are better than PE, and the aging resistance is better. Often used in places with high environmental resistance requirements.

Technical Specifications
Conductor AWG Pair/Triad Count Conductor Strand Class/Stranding Nominal Insulation Thickness (mm) Nominal Jacket Thickness (mm) Nominal Cable O.D. (mm) Approximate Cable Weight Lbs/Mft (Kg/Km)
18AWG1 pairB/70.030 (0.8)0.045 (1.1)0.320(8.2)49 (73)
18 AWG2 pairB/70.030 (0.8)0.045 (1.1)0.490(12.5)128(190)
18 AWG4 pairB/70.030 (0.8)0.060 (1.5)0.680(17.3)190(283)
18 AWG8 pairB/70.030 (0.8)0.060 (1.5)0.810(20.7)332(494)
18AWG12 pairB/70.030 (0.8)0.080 (2.0)0.960(24.5)486(723)
18AWG16 pairB/70.030 (0.8)0.080 (2.0)1.090(27.8)605(900)
18AWG24 pairB/70.030 (0.8)0.080 (2.0)1.430(36.5)960(1428)
18 AWG1 triadB/70.030 (0.8)0.045(1.1)0.330(8.4)60 (89)
18 AWG2 triadB/70.030 (0.8)0.045(1.1)0.550(14.0)152(226)
18 AWG4 triadB/70.030 (0.8)0.060(1.5)0.720(18.4)261(388)
18AWG8 triadB/70.030 (0.8)0.080 (2.0)0.920(23.5)454(676)
18AWG12 triadB/70.030 (0.8)0.080(2.0)1.110(28.3)627(933)
18 AWG16 triadB/70.030 (0.8)0.080(2.0)1.150(29.3)771 (1147)
18 AWG24 triadB/70.030 (0.8)0.080 (2.0)1.530(39.0)1218(1812)
16AWG1 pairB/70.030 (0.8)0.045(1.1)0.340(8.7)62 (92)
16 AWG2 pairB/70.030 (0.8)0.045(1.1)0.540(13.8)153 (228)
16AWG4 pairB/70.030 (0.8)0.060(1.5)0.670(17.1)255(379)
16AWG8 pairB/70.030 (0.8)0.060(1.5)0.850(21.7)408(607)
16 AWG12 pairB/70.030 (0.8)0.080(2.0)1.060(27.0)610(908)
16AWG16 pairB/70.030 (0.8)0.080 (2.0)1.230(31.4)770(1146)
16AWG24 pairB/70.030 (0.8)0.080 (2.0)1.380(35.2)1175(1748)
16AWG1 triadB/70.030 (0.8)0.045(1.1)0.370 (9.4)78(116)
16AWG2 triadB/70.030 (0.8)0.060(1.5)0.630(16.1)209 (311)
16 AWG4 triadB/70.030 (0.8)0.060(1.5)0.740(18.9)349 (519)
16 AWG8 triadB/70.030 (0.8)0.080 (2.0)1.030(26.3)578(856)
16 AWG12 triadB/70.030 (0.8)0.080 (2.0)1.220(31.1)803(1195)
16 AWG16 triadB/70.030 (0.8)0.080 (2.0)1.360(34.7)1010(1503)
16 AWG24 triadB/70.030 (0.8)0.080(2.0)1.590(40.6)1549(2305)
Flexible Twisted 24 Pairs Shielded Instrument Cable With XLPE PVC Insulation Copper Conductor
